The short answer
As a California commercial planning range as of 2026, a commercial Wi-Fi access point runs roughly $700 to $2,400 installed for an interior unit in an accessible ceiling and about $1,800 to $4,500 for an outdoor unit. That covers the access point, mount, the Cat6A drop, the switch port share and configuration. Add predictive design, an on site survey, validation and cloud licensing of about $50 to $300 per access point per year, and a whole building lands closer to $1,700 to $4,000 per access point all in. The access point count comes from a survey rather than square footage. Plaster and wire lath, concrete, foil faced insulation and a per unit coverage target in multifamily can double the count a floor area estimate would suggest.
| Interior AP range | About $700 to $2,400 installed, California 2026 |
|---|---|
| Outdoor AP range | About $1,800 to $4,500 installed |
| Cloud licensing | About $50 to $300 per AP per year |
| All in per AP | About $1,700 to $4,000 with survey and switching |
| AP count source | Survey and construction type, not square footage |
| License | CSLB #472017, C-7 Low Voltage Systems |
Per access point planning ranges for California in 2026
Wireless is priced by the access point, then adjusted for the building and the design work around it. The figures below are California commercial planning ranges as of 2026. Use them for budgeting. They aren’t quotes.
Each range covers the access point, the mount or bracket, and the Cat6A drop from the access point to the nearest IDF, with termination, labeling and certification test. It also includes the switch port share and the per access point share of configuration. The ranges don’t include predictive design, the on site survey, the validation survey, controller or cloud licensing, switch chassis beyond the port share, electrical work or any pathway built by another trade.
| Position | Planning range per access point, installed |
|---|---|
| Interior, Wi-Fi 6, grid ceiling, unoccupied | About $700 to $1,300 |
| Interior, Wi-Fi 6, grid ceiling, occupied with some night work | About $900 to $1,700 |
| Interior, Wi-Fi 6E or Wi-Fi 7, grid ceiling, unoccupied | About $1,000 to $1,900 |
| Interior, Wi-Fi 6E or Wi-Fi 7, grid ceiling, occupied | About $1,200 to $2,400 |
| Interior, hard lid ceiling, box and pathway set or cable fished, occupied | About $1,600 to $3,200 |
| In unit or wall plate access point, occupied multifamily or senior housing | About $800 to $1,800 |
| Outdoor, courtyard, entry canopy or parking, surge protected | About $1,800 to $4,500 |
If you’re adding a single access point to an existing network, expect it to land above these bands. A campus rollout of two hundred identical interior positions tends to land toward the low end of each row.
What goes into a per access point price
| Component | What it covers | Planning range per AP |
|---|---|---|
| Access point, Wi-Fi 6 | Indoor dual band unit, 802.3at powered | $250 to $700 |
| Access point, Wi-Fi 6E or Wi-Fi 7 | Tri band unit, often 802.3bt with a multigigabit uplink | $600 to $1,600 |
| Access point, outdoor | Weather rated enclosure, antennas, surge protection | $700 to $2,000 |
| Mount, bracket, tile bridge, box or pole arm | Listed hardware for the ceiling or the surface | $30 to $250 |
| Cat6A drop | Terminated, labeled and certification tested | $200 to $600 |
| PoE switch port share | Port and switch PoE budget at 802.3at or 802.3bt | $100 to $350 |
| Per AP configuration share | Naming, placement record, radio and channel settings | $100 to $300 |
The drop line uses the Cat6A ranges from our structured cabling cost guide. Cat6A is the usual specification for access point drops, even in buildings where the workstations are on Cat6. It carries multigigabit Ethernet to the full 100 meters, and it can stay in the ceiling through several access point generations. The Cat6 versus Cat6A guide covers when that premium is worth paying.
Why the AP count comes from a survey instead of square footage
There’s no reliable access point count per square foot. Two buildings with the same floor plate can need very different counts, and the difference comes down to construction and the coverage target.
Construction type. Drywall on steel studs passes signal reasonably well. Plaster over wire lath, common in older towers, acts like a partial shield. Concrete, CMU and tilt up panels attenuate the signal heavily, and foil faced insulation in a warehouse roof or an exterior wall reflects it. Elevator shafts, stairwells, fire rated corridors and metal shelving all create shadows that a plan set won’t show you.
Ceiling type. A grid ceiling gives you freedom in placement and cheap drops. A hard lid ceiling means boxes and pathways have to go in during rough in, and moving an access point after the drywall is closed is expensive. With exposed structure, the mount and the cable will be seen, so the design has to look intentional.
Coverage target versus capacity target. A coverage design places access points so the signal reaches everywhere. A capacity design places them so a room full of clients gets enough throughput. A lecture hall, an all hands room or a conference center needs smaller cells at lower transmit power, and more access points per room than coverage alone would call for.
Per unit coverage in multifamily and senior housing. When the unit is the coverage target, the count depends on the unit count and wall construction rather than corridor length. Depending on the building, that means an access point in each unit, a corridor access point serving units on both sides, or a wall plate access point that also provides wired ports. Corridor only coverage is cheaper, but it often doesn’t deliver a usable signal through plaster or concrete demising walls. Little Tokyo Towers and Horton House were both occupied buildings that received property wide Wi-Fi.
Outdoor coverage. Courtyards, pool decks, parking areas and quads need weather rated units, outdoor rated cable, surge protection at the building entrance, and often a pole or canopy mount. On most projects, outdoor positions are the most expensive per access point.
Design work gets its own line, and it’s a small share of the project.
| Design and validation item | Planning range |
|---|---|
| Predictive design and channel plan, single building | About $2,000 to $5,000 |
| On site survey with a test access point before design freeze | About $2,500 to $7,000 |
| Post installation validation survey and report | About $1,500 to $5,000 |
| Campus or multi building design, per additional building | About $1,000 to $3,500 |
Licensing, lifecycle and where under investing costs more
| Item | Planning range or service life | Notes |
|---|---|---|
| Cloud or controller license, per AP per year | About $50 to $300 | Multi year terms lower the annual figure; some vendors bundle years into the hardware |
| Support and firmware entitlement | Usually inside the license | Confirm what a lapsed license disables before standardizing |
| Access point service life | About 5 to 8 years | Replaced when the radio generation, not the hardware, becomes the limit |
| PoE switch service life | About 7 to 10 years | Replaced for PoE budget and multigigabit ports more often than for failure |
| Cat6A cabling and pathway service life | About 15 to 25 years | Outlasts two or three access point generations |
This table makes the case for spending on infrastructure. The access point has the shortest life in the system and is the easiest part to replace. The cable in the ceiling and the switch in the IDF are the expensive parts to change. They also decide whether the next generation of access points can simply be swapped in or needs a second pull. Specifying Cat6A drops and a switch with 802.3bt headroom and multigigabit ports costs more on day one, and it can take the largest cost out of the next refresh.
Switch cost depends on what the switch is feeding. A switch for cameras and phones at gigabit with 802.3at typically runs about $1,500 to $4,500 installed. A switch for Wi-Fi 6E or Wi-Fi 7 access points, with multigigabit access ports and an 802.3bt budget, typically runs about $3,000 to $8,000 installed. Counting the PoE budget per switch, rather than per port, helps keep access points from dropping radios at peak load.
A worked example: 39 access points in a three floor office
Assumptions: a single tenant office on three floors totaling about 54,000 sq. ft., occupied during the work with some after hours shifts. Most floors have a 2 by 4 grid ceiling, with hard lid at the lobby and the executive suite. There’s one IDF per floor with an existing tested backbone and spare rack space. Wi-Fi 6E is specified, with a coverage plus capacity design. The survey returns 30 interior access points in grid ceiling, 6 in hard lid areas and 3 outdoor units at the courtyard and entry canopy, for 39 total. The owner is private, so there’s no prevailing wage.
| Line item | Quantity | Planning range | Extended planning range |
|---|---|---|---|
| Predictive design and channel plan | 1 building | $2,000 to $5,000 | $2,000 to $5,000 |
| On site survey with a test access point | 1 building | $2,500 to $7,000 | $2,500 to $7,000 |
| Interior Wi-Fi 6E access points, grid ceiling, occupied | 30 | $1,200 to $2,400 | $36,000 to $72,000 |
| Interior Wi-Fi 6E access points, hard lid lobby and suite | 6 | $1,600 to $3,200 | $9,600 to $19,200 |
| Outdoor access points, courtyard and entry canopy | 3 | $1,800 to $4,500 | $5,400 to $13,500 |
| PoE switches, 802.3bt budget with multigigabit access ports | 3 | $3,000 to $8,000 | $9,000 to $24,000 |
| Validation survey, closeout package and credential turnover | 1 | $1,500 to $5,000 | $1,500 to $5,000 |
| Cloud licensing, year one | 39 | $50 to $300 | $1,950 to $11,700 |
| Planning total, year one, low voltage scope | About $68,000 to $157,400 |
That works out to roughly $1,700 to $4,000 per access point all in. The assumptions drive the number, so it helps to see what happens when you change them. If the building is unoccupied, the interior lines drop toward the lower rows. Make it a public agency job and the installed lines go up. On a planning assumption that labor is about 60 percent of an installed access point, a 40 percent determination moves that line about 24 percent, and the hardware and licensing lines don’t change. Specify Wi-Fi 6 instead of 6E and the access point and switch lines both fall, but the next refresh likely comes sooner. If it’s occupied multifamily with the unit as the coverage target, the count drives the total more than the per unit price does. Our wireless networks page describes what a complete scope includes, and our multifamily and affordable housing page covers how we phase occupied properties.
Next step
To price a wireless network, we need floor plans, a description of the wall and ceiling construction, the occupant or unit count, and the applications the network has to carry. You can send them through request a bid. We’ll send back an access point count from a predictive model, with the cabling and switching priced separately from the wireless hardware, the survey and validation as their own lines, and the PoE budget worked out per switch. Telelink Business Services is a licensed C-7 Low Voltage Systems Contractor, CSLB License #472017. General contractors can find our Division 27 bid and coordination process on the for general contractors page.
