Why the parking garage is a separate low voltage scope
Hospitals, universities, state office buildings, senior campuses and Class A offices often come with a garage attached. The garage is drawn on its own sheet set, bid on its own schedule and finished after the building it serves. The low voltage subcontractor who spent a year inside the building often never priced the deck. That can leave the garage with only what happened to be drawn on the deck sheets, even though cars and people move through it around the clock.
Telelink Business Services is a licensed C-7 Low Voltage Systems Contractor, CSLB License #472017. We don’t have a published parking structure project to show you yet. The work in a deck, though, is the same camera, intercom, access control, outdoor cable and fiber work we self-perform in buildings, built to TIA-568, TIA-569 and TIA-606. You can see those methods in our published projects at the State Controller’s Office and Touro University. We’ll bid a garage as part of the building’s systems, on the same head end, access control platform and labeling scheme, or as a standalone scope on an existing deck. When the garage serves a hospital or clinic campus, a university, or a state or county office building, the building’s rules carry over to the deck. That means the same badging, the same after-hours windows and the same closeout package.
What we self-perform in a deck
The environment is tougher, but the scope list will look familiar. It includes camera systems and their coverage layout, intercom wiring and head end, access control field devices and controllers, and outdoor rated cable in raceway with firestopped and waterproofed penetrations. It also includes singlemode fiber between levels, terminated and tested. The standards don’t change either: TIA-568 and TIA-569 for cabling and pathway, TIA-606 for labeling, and Tier 1 fiber testing with Tier 2 OTDR traces where the specification calls for them.
At the State Controller’s Office in Sacramento, we did cabling, a network room and surveillance on an occupied state agency floor, working around agency hours and badging rules. At Touro University in Vallejo, we tied a campus building back on a fiber backbone we installed, spliced and tested. A parking structure adds exposure, distance and vehicle traffic to those same systems, and our bid explains how we handle each one.
How camera design changes in a parking deck
The camera problems in a garage are optical ones, and a camera schedule copied from the office floors above usually won’t solve them.
Dynamic range at the portals. Entry and exit portals are often the hardest scenes on the property. You have full California sun on one side of the opening, a dark deck on the other, and a vehicle moving between the two. We specify portal cameras for wide dynamic range and set them up to capture the plate and the driver rather than a nice-looking overall image.
Low light on ramps and stairs. At night, deck lighting on upper levels and in stair cores frequently measures below 1 lux at the floor. If the camera was rated for more light than the deck has, you can get a smear where a face should be. We specify sensors that hold usable detail at the light level we measure on site. Where that level won’t support the identification the owner wants, we add supplemental infrared or white light.
Impact and vandalism. We use IK10 vandal resistant housings, mounted clear of truck mirrors and out of reach of someone standing on a car roof. Enclosures are rated for washdown, and for salt air on coastal sites.
Camera count and the structural grid. A deck is a repeating grid of columns and beams, and every column blocks a view. So the camera count depends on column spacing, ramp geometry, where the stair and elevator cores are and how many portals there are, rather than on square footage. We lay out coverage on the structural grid using the camera coverage calculator and the deck plans, then check the views at noon and at night. The security camera page covers platforms, storage sizing and NDAA Section 889 documentation.
ALPR, PARCS and the equipment in each lane
ALPR at the entry and exit lanes creates a plate record tied to a time and a lane, and that record helps settle a lost ticket dispute. It also brings a California compliance obligation along with the hardware.
California Civil Code sections 1798.90.5 through 1798.90.55 govern automatic license plate recognition. A private ALPR operator must adopt a usage and privacy policy, post that policy conspicuously on its website, log every access to ALPR information, and define a retention period. Public agencies operating ALPR face additional restrictions. Those duties fall on whoever operates the system. We install and maintain the ALPR hardware, while operating the system, hosting the data and granting access to ALPR information stay with the operator. The owner should have the policy, the access log and the retention schedule written before the lanes go live.
The parking operator or the PARCS vendor normally furnishes the parking access and revenue control equipment (gate arms, ticket dispensers, pay-on-foot stations and validators). We handle the low voltage side: the network to each lane, the intercom from the lane back to a remote attendant, the pathway and the pull, and the interface points to the controller. The gate operator itself, its line voltage feed and its safety and entrapment protection devices belong to the gate contractor and the electrician. Our bid lists each of those trades, so each trade’s part is on paper.
California codes that affect a parking garage low voltage bid
Two California requirements affect a garage bid. Each one has a different authority and a different trade boundary, and we spell out both in our bid.
| Requirement | What it says | Who carries it |
|---|---|---|
| Civil Code 1798.90.5 to 1798.90.55 | An ALPR operator adopts and posts a usage and privacy policy, logs every access to ALPR information and sets a retention period; public agencies face additional restrictions | The operator. Telelink installs and maintains the hardware |
| Title 24 Part 6 Section 130.1(c)(7) | The subsection holding the parking garage lighting control requirements: occupant sensing control, at least one control step between 20 and 50 percent of design lighting power, and no more than 500 watts as a single zone | The electrician. Telelink coordinates the control wiring and the shared pathway |
Cable, pathway and the fiber backbone between decks
Cable runs in a deck are long, and the electrical environment is hard on them. In a large structure you can hit the 100 meter copper channel limit inside a single level. The head end is hundreds of feet from the far corner, and the building is full of motor loads, gate operators and lighting circuits. So the backbone between levels and back to the building is singlemode fiber in raceway, with a fiber switch or media converter in a weatherproof enclosure at each level.
The other challenge is exposure. A deck has no ceiling to hide cable in and no conditioned air, so we use outdoor rated cable and run it in raceway wherever it’s exposed. Penetrations through rated assemblies are firestopped to the listed system. Penetrations through the deck slab are waterproofed, flashed and coordinated with the waterproofing contractor before they’re cored, because a garage slab is also the roof of the level below. Outdoor runs get surge protection at both ends, and enclosures are gasketed and rated for washdown. Where the design allows, head end equipment stays inside the building. Wayfinding signs and space count sensors use the same infrastructure, and we coordinate sign power with the electrician.
Next step
Send the garage sheets, the structural grid, the lighting plan and the list of systems through the request a bid page, and we’ll put together a bid. It will show the camera count laid out on the column grid, the ALPR hardware kept separate from the operator’s duties, and the fiber routes between levels drawn in. Lighting control and the gate operator are listed as separate trades, so it’s clear where our scope stops.
